可修改的应用、可定制的试验模板、可设置不同的安全访问级别，满足精准要求，契合测试计划的应用软件平台。无论是执行符合行业标准、规范的材料力学性能试验还是产品研发所需的部件试验，MTS TestSuite测试应用软件平台所包含的工具能够让您轻松、快速地获取足够的测试数据，得出准确的试验结论。
应用
- 动态特征参数
- 疲劳和断裂
- 静力测试
测试样件
- 复合材料
- 陶瓷
- 金属
- 塑料
- 粘弹性材料
- 橡胶
- 聚合物
试验标准
- ASTM A48-A48M
- ASTM D2344
- ASTM D3039
- ASTM D3518
- ASTM D412
- ASTM D5023
- ASTM D5024
- ASTM D5026
- ASTM D5418
- ASTM D5992
- ASTM D624
- ASTM D6272
- ASTM D638
- ASTM D695
- ASTM D7028
- ASTM D7264
- ASTM D790
- ASTM D882
- ASTM E21
- ASTM E290
- ASTM E517
- ASTM E646
- ASTM E8-E8M
- ASTM E9
- ASTM F543
- ISO 10113
- ISO 10275
- ISO 6892-1
- ISO 6892-2
- ISO 7438
- ISO 14129
- ISO 14801
- ISO 178
- ISO 527-2
- ISO 527-3
- ISO 527-4
- ISO 527-5
- ISO 604
- ISO 6721-12
- ISO 6721-4
- ISO 6721-5
- EN 2561
- EN 2562
- EN 2746
- EN 6031
- EN 2597
产品主要特点
简单
图形化显示、图形化编程，轻松设置与开发
快速
虚拟样件功能可节约测试设置和执行时间
强大
内置 Iron Python 编程语言用于扩展测试应用
宽泛
平台化软件多模块设计，兼容多种测试系统与应用
产品对比
TestSuite TW
- 与 Criterion 和 Exceed 机电伺服短时力学测试系统配合使用
- 兼容 Landmark、311 、 322 等使用FlexTest数字控制器的电液伺服测试系统
- 借助 ReNew 升级，可与其他万能试验系统配合使用
- 模块：
- TW精英版(TWE) - 创建、编辑、运行测试的全功能软件模块
- TW基础版(TWS) - 精英版的简化版，包含有限数量的功能
- TW快捷版(TWX) - 仅用于运行测试
- 包含各类测试的应用模板，可定制开发模板
- 图形化显示，图形化编程
TestSuite MP
- 与 Landmark、Acumen、Bionix 等使用FlexTest数字控制器的测试系统配合使用
- 模块：
- MP精英版(MPE) - 创建、编辑、运行测试的全功能软件模块
- MP快捷版(MPX) - 仅用于运行测试
- 疲劳、断裂和拉伸模块
- 可执行各类动静态、短时力学、疲劳与断裂测试应用
- 包含符合标准的材料力学测试模板，可开发定制模板
- 实现自动PID调优，可以实现轴扭组合系统自动调优
- 实时显示计算结果
- 可视化显示限值
- 虚拟样件功能可准确预测测试行为
技术概要
|
Sample of the many Metals test standards that can be addressed using MTS TestSuite TW templates |
|
| Standard | Description |
|
ASTM E8M |
Standard Test Methods for Tension Testing of Metallic Materials |
|
ISO 6892-1 |
Metallic Materials – Tensile testing at ambient temperature |
|
EN 10002-1 |
Tensile Testing of Metallic Materials |
|
ASTM E9 |
Standard Test Methods of Compression Testing of Metallic Materials at Room Temperature |
|
ASTM E290 |
Standard Test Methods for Bend Testing of Material for Ductility |
|
ISO 7438 |
Metallic Materials – Bend Test |
|
ASTM E21 |
Standard Test Methods for Elevated Temperature Tension Tests of Metallic Materials |
|
ISO 783 |
Metallic Materials – Tensile testing at elevated temperature |
|
ASTM E517 |
Standard Test Method for Plastic Strain Ratio r for Sheet Metal |
|
ASTM E646 |
Standard Test Method for Tensile Strain-Hardening Exponents (n-Values) of Metallic Sheet Materials |
|
ASTM A48M |
Standard Specification for Gray Iron Castings |
|
ASTM A370 |
Standard Test Methods for Mechanical Testing of Steel Products |
|
Sample of the many Polymer test standards that can be addressed using MTS TestSuite TW templates |
|
| Standard | Description |
|
ASTM D790 |
Standard Test Methods for Flexural Properties of Unreinforced and Reinforced Plastics and Electrical Insulating Materials |
|
ASTM D412 |
Standard Test Methods for Vulcanized Rubber and Thermoplastic Elastomers – Tension |
|
ASTM D624 |
Standard Test Method for Tear Strength of Conventional Vulcanized Rubber and Thermoplastic Elastomers |
|
ASTM D638 |
Standard Test Method for Tensile Properties of Plastics |
|
ASTM D695 |
Standard Test Method for Compressive Properties of Rigid Plastics |
|
ISO 178 |
Plastics – Determination of flexural properties |
|
ISO 1798 |
Flexible cellular polymeric materials – Determination of tensile strength and elongation at break |
|
ISO 527 |
Plastics – Determination of tensile properties |
|
ISO 604 |
Plastics – Determination of compressive properties |
|
ASTM D882 |
Standard Test Method for Tensile Properties of Thin Plastic Sheeting |
|
Sample of the many Construction Materials test standards that can be addressed using MTS TestSuite TW templates |
|
| Standard | Description |
|
ASTM A370 |
Tensile Testing & Bend Testing Steel Rebar |
|
ISO 15630 |
Steel for the reinforcement and pre-stressing of concrete – Test methods – Part 1: Reinforcing bars, wire rod and wire |
|
ISO 1920-4 |
Testing of concrete – Part 4: Determination of flexural strength; Determination of tensile splitting strength |
|
ASTM A185/ A185M |
Standard Specification for Steel Welded Wire Reinforcement, Plain, for Concrete |
|
ASTM A615M |
Standard Specification for Deformed and Plain Carbon-Steel Bars for Concrete Reinforcement |
|
ASTM A82/ A82M |
Standard Specification for Steel Wire, Plain, for Concrete Reinforcement |
|
EN 10080 |
Steel for the reinforcement of concrete. Weldable reinforcing steel |
|
ISO 15630-2 |
Steel for the reinforcement and pre-stressing of concrete – Test methods – Part 2: Welded fabric |
|
ASTM F606 |
Standard Test Methods for Determining the Mechanical Properties of Externally and Internally Threaded Fasteners |
|
Sample of the many Polymer Matrix Composite test standards that can be addressed using MTS TestSuite TW templates |
|
| Standard | Description |
|
ISO 527-4 |
Tensile Properties of Isotropic and Orthotropic Fibre-Reinforced Plastic Composites |
|
ISO 527-5 |
Tensile Properties of Unidirectional Fibre-Reinforced Plastic Composites |
|
ASTM D3039 |
Tensile Properties of Polymer Matrix Composite Materials |
|
ISO 14126 |
In-plane Compressive Properties of Fibre-Reinforced Plastic Composites |
|
ASTM D6641 |
Compressive Properties of Polymer Matrix Composite Materials Using a Combined Loading Compression (CLC) Test Fixture |
|
ISO 14125 |
Flexure Properties of Fibre-Reinforced Plastic Composites |
|
ISO 14129 |
In-Plane Shear Stress/Shear Strain Response of Fibre-Reinforced Plastic Composites |
|
ASTM D3518 |
In-Plane Shear Response of Polymer Matrix Composite Materials |
|
ISO 14130 |
Fibre-Reinforced Plastic Composite – Determination of Apparent Interlaminar Shear Strength by Short-Beam Method |
|
ASTM D2344 |
Short-Beam Strength of Polymer Matrix Composite Materials and Their Laminates |
We can provide pre-packaged templates for a wide array of additional materials, including: textiles, paper products, packaging, adhesives, foam, composites and more.
MTS TestSuite Fatigue Modules and Supported Standards
|
Fatigue Modules |
Scope |
ASTM Standards |
Contents |
|
Low-Cycle Fatigue |
LCF testing up to 12 Hz |
E606 |
Test Template |
|
|
|
D3479 |
Report Template |
|
|
Includes templates for LCF and |
|
Analysis Definition |
|
|
transition to HCF tests |
|
|
|
High-Cycle Fatigue |
High-cycle fatigue testing up to 70 Hz |
E466 |
Test Template |
|
|
|
D3479 |
Report Template |
|
|
|
|
Analysis Definition |
|
Advanced Low-Cycle Fatigue |
Constant-amplitude, strain-controlled |
E606 |
Test Template |
|
|
fatigue testing up to 12 Hz |
D3479 |
Report Template |
|
|
|
|
Analysis Definition |
|
|
Calculates and corrects for thermal expansion |
|
Custom Wave Form Activity |
|
|
during non-ambient temperature testing |
|
|
|
Advanced High-Cycle Fatigue |
High-cycle fatigue testing up to 70 Hz |
E466 |
Test Template |
|
|
|
D3479 |
Report Template |
|
|
Calculates and corrects for thermal expansion |
|
Analysis Definition |
|
|
during non-ambient temperature testing |
|
|
|
Thermomechanical Fatigue (TMF) |
Thermomechanical fatigue testing |
E2368 |
Test Template |
|
|
|
European Validated Code of |
Report Template |
|
|
|
Practice for Strain-Controlled |
|
|
|
|
TMF Testing EUR 22281 EN |
|
MTS TestSuite Fracture Modules and Supported Standards
|
Fracture Modules |
Scope |
ASTM Standards |
Contents |
|
Clip Gage Fatigue Crack Growth |
Fatigue crack growth testing using a |
E647 |
Test Template |
|
|
clip gage and compliance method |
|
Report Template |
|
|
as measurement |
|
Analysis Definition |
|
Direct Current Potential Drop (DCPD) Fatigue Crack Growth |
Fatigue crack growth tension testing using DCPD systems to measure crack length |
E647 |
Test Template Report Template |
|
|
|
|
Analysis Definition |
|
KIc Fracture Toughness |
Fatigue pre-cracking, using the compliance |
E399 |
Test Template |
|
|
method as primary crack length measurement |
|
Report Template |
|
|
|
|
Analysis Definition |
|
Crack-Tip Opening Displacement (CTOD) Fracture Toughness |
Determines critical CTOD values at one or more of several crack extension events |
E1290 |
Test Template Report Template |
|
|
|
|
Analysis Definition |
|
|
CTOD values can be used as measures |
|
|
|
|
of fracture toughness |
|
|
|
JIc-CTOD Fracture Toughness |
Fatigue pre-cracking, using the compliance |
E1820 |
Test Template |
|
|
method as primary crack length measurement |
|
Report Template |
|
|
|
|
Analysis Definition |
